high capacity Double head ABA Three layers Co-extrusion Film blowing machine

Name: high capacity Double head ABA Three layers Coextrusion Film blowing machine
Brand: SANBI
Price: 40000 USD

Buy cheap high capacity Double head ABA Three layers Co-extrusion Film blowing machine product

Brand Name : SANBI

Model Number : SJABA 600 / SJ-ABA800

Certification : CE, ISO9001

Place of Origin : CHINA

MOQ : 1 sets

Price : 40000-50000USD

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 30 sets of month

Delivery Time : within 30 workdays

Packaging Details : wooden package

Material : HDPE,.LDPE. CACO3

Screws : Double layers co-extrusion screw

capacity : 60-80kgs

head model : ABA double head

rewinder : automatic rewinder

Certificate : CE

Contact Now

CE Double head ABA Three layers Co-extrusion Film blowing machine

Quick Detail:
3 Layers Co-extrusion Film Blowing Machine
1. ABA Three layers double die head
2. automatic double rewinder
3. mix CaCo3 save PE material
4. high capacity . cheaper than ABC type three layers machine

Condition	New
Application	Film
Plastic Processed	pe
Blow Moulding Type	Extrusion Blow Moulding
Automatic	Yes
Place of Origin	Zhejiang, China (Mainland)
Brand Name	SANBI
Model Number	SJ-55X55FM650
Material	LDPE,HDPE, Can mix CaCo3
Layers	3 layers
Extusion	Co-extrusion
Capacity	100-120KGS
Die head	DOUBLE HEAD
Winder	AUTOMATIC REWINDER
Certificate	CE,ISO

Description:
3-layers ABA co-extrusion blowing film machine enjoys special advantages and can produce both HDPE and LDPE Film. it improve the physical toughness of film through multi-layers co-extrusion. with one main extruder providing material for outer and inner layer. it reduces one man extruder configurations and achieves energy saving and low consumption.

Applications:

The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home.
bsp;film through multi-layers co-extrusion. with one main extruder providing material for outer and inner layer. it reduces one man extruder configurations and achieves energy saving and low consumption.

Specifications:

	MODEL	ABA55X2X800X2F
FEATURE	SUITABLE MATERIAL	HDPE
	LAYER NUMBER	3-ABA
	FILM THICKNESS	0.008-0.05MM
	MAX OUTPUT	100-140KG/H
	MAX FILM WIDTH	700MM
EXTRUSION UNIT	SCREW DIAMETER	Φ55X2
	SCREW L/D RATIO	30/1
	SCREW MATERIAL	BIMETALLIC
	BARREL THERMO CONTROL	6
	BARREL COOLING FAN	200W
	SCREEN CHANGER	LONG TYPE
	DRIVING MOTOR	22KWX2
EXTRUSION DIE UNIT	DIE DIAMETER	HDABAΦ100 X 2
	DIE THEROMO CONTROL	2X2
	AIR RING	DOUBLE LIP
	FLANGE THERMO CONTROL	2
	AIR BLOWER	3.7KW X 2
TAKE-UP UNIT	TAKE-UP ROLLER LENGTH	800MM X 2
	EMBOSSING ROLLER	2
	GUSSET	2
	TAKE-UP MOTOR	1.5KWX2
	TAKE-UP SPEED	10-100M/MIN
WINDING UNIT	WINDING TYPE	SINGLE FRICTION WINDER X2
	WINDING ROLLER LENGTH	500MM X 2
	MAX DIA.OF WINDED ROLL	800MM
	WINDING MOTOR	1.5KW

Competitive Advantage:

high capacity Double head ABA Three layers Co-extrusion Film blowing machine

high capacity Double head ABA Three layers Co-extrusion Film blowing machine
